Berchtold Podo-Q Dust Extraction Drill

* Free Service with every Berchtold Podo Q purchased, valid for 14 months.*

The Berchtold Podo-Q Dust Extraction Drill is a compact, high-performance electric drill designed for professional foot and nail treatments where effective dust extraction, precise speed control and comfortable operation are essential.

Combining Berchtold’s established engineering with a modern, space-efficient design, the Podo-Q provides powerful and reliable dust extraction through low-maintenance, brushless motors. The quiet-running extraction system helps remove dust and debris generated during drilling and filing procedures, supporting a cleaner and more comfortable environment.

Three programmable memory settings allow preferred speed and suction levels to be stored for quick access, reducing the need to repeatedly adjust the controls between uses. The compact 2.5kg unit also has a slim profile, making it suitable for treatment rooms where workspace is at a premium.

Key Features and Benefits

• Powerful dust extraction for effective collection of dust and debris generated during drilling and filing
• Low-maintenance brushless motor technology for reliable, quiet operation
• Variable drill speed from 5,000–25,000 rpm for controlled treatment
• Touch and slide controls for intuitive adjustment during use
• Three programmable memory settings for frequently used speed and suction combinations
• Compact and lightweight design, weighing approximately 2.5kg
• Designed for professional foot and nail treatment environments
• Supplied with a 14-month free service from Canonbury
• Drill speed 5,000–25,000 rpm
• Dimensions 30 × 11 × 27cm (W × H × D)
• Weight 2.5kg
• Power supply 220/240V

How to use

Basic Operation

Power: Switch on the device.
Settings: Adjust speed, suction, and rotation using the touch display.
Speed: 5,000–25,000 RPM.
Suction: 3 levels.
Direction: Select rotation direction on screen.

Handpiece

Insert Burr: Push in a standard 2.35 mm burr; it locks automatically.
Start/Stop: Use the handpiece on/off switch.
Memory: Save settings using 3 programmable keys.

Maintenance

Filter Bag: Replace when the “Bag Full” indicator appears.
Cleaning: Open the handpiece tip for tool-free cleaning.

Primary Uses

Diabetic Foot Care: Safe nail and hard-skin debridement with controlled speed and suction.
Thick Nails: Reduce hypertrophic, hardened nails using diamond or carbide burs.
Fungal Nails: Debride brittle nails to support topical treatment.
Corns: Precisely remove painful corn cores.
Calluses & Fissures: Smooth thick skin and cracked heels.
Nail Edges: Clear debris around nail folds to help prevent ingrown nails.

FAQs

What is the operational speed range of the drill?
The brushless micromotor features continuously adjustable speeds ranging from 5,000 to 25,000 RPM

How heavy and portable is the unit?
Console weighs 2.3–2.5 kg; handpiece weighs 100–140 g making suitable for smaller rooms or on the go.

How do the touch controls handle clinical environments?
Glove-friendly touch-and-slide glass controls.

Can I save custom operational profiles?
Yes. The interface includes 3 programmable keys for speed, suction, and rotation settings.

What type of filtration mechanism does it use?
3-layer micro-filter bags capture fungal, bacterial, and viral particles; Bag Full indicator included.

Can the handpiece be serviced by the user?
Yes. Unlike older generations, the Podo-Q handpiece features a robust aluminium casing handpiece can be opened and cleaned without tools.

What kind of burs does it support?
It features an automatic gripping mechanism that accommodates standard 2.35 mm (3/32 inch)

Important: The Berchtold Podo-Q is not classified as a Medical Device and is compliant for use in the Beauty Industry only. Please ensure the product is appropriate for your intended application before purchase.
